Hook Lift Trucks - 400 Series Hook Lifts
sl330

SL-330 (33,000 lb. Capacity) Hook Lift

  • Recommended CT: 138″
  • GVW Range: 33,000 lb. or Greater
  • Required Clear Frame (useable) Rail: 191″
  • Chassis Frame Height: Up to 43″
  • Body Lengths: 14′ to 18′
  • Body Lengths w/CVS Option: 12′ to 18′
  • Hook Height: Fixed 62″ or Adjustable 54″ to 62″
  • Flow: 22.3 GPM @ 1,500 RPM
  • PSI: 3,500
  • Extras: SL-330 Bid Specs, SL-330 Manual & Adjustable Jib Instructions
  • See “400 Series Hoist Links” to the right, for more details.
sl400

SL-400 (40,000 lb. Capacity) Hook Lift

  • Recommended CT: 138″
  • GVW Range: 45,000 lb. or Greater
  • Required Clear Frame (useable) Rail: 191″
  • Chassis Frame Height: Up to 43″
  • Body Lengths: 14′ to 18′
  • Body Lengths w/CVS Option: 12′ to 18′
  • Hook Height: Fixed 62″ or Adjustable 54″ to 62″
  • Flow: 22.3 GPM @ 1,500 RPM
  • PSI: 3,500
  • Extras: SL-400 Bid Specs, SL-400 Manual & Adjustable Jib Instructions
  • See “400 Series Hoist Links” to the right, for more details.
sl406

SL-406 (40,000 lb. Capacity) Hook Lift

  • Recommended CT: 180″
  • GVW Range: 45,000 lb. or Greater
  • Required Clear Frame (useable) Rail: 232″
  • Chassis Frame Height: Up to 45″
  • Body Lengths: 18′ to 22′
  • Body Lengths w/CVS Option: 16′ to 22′
  • Hook Height: Fixed 62″ or Adjustable 54″ to 62″
  • Flow: 22.3 GPM @ 1,500 RPM
  • PSI: 3,500
  • Extras: SL-406 Bid Specs & SL-406 Manual
  • See “400 Series Hoist Links” to the right, for more details.

SL-412 (40,000 lb. Capacity) Hook Lift

  • Recommended CT: 114″
  • GVW Range: 45,000 lb. or Greater
  • Required Clear Frame (useable) Rail: 169″
  • Chassis Frame Height: Up to 45″
  • Body Lengths: 12′ to 15′
  • Hook Height: Fixed 62″ or Adjustable 54″ to 62″
  • Flow: 22.3 GPM @ 1,500 RPM
  • PSI: 3,500
  • Extras: SL-412 Bid Specs &  SL-412 Manual
  • See “400 Series Hoist Links” to the right, for more details.

SL-520 (50,000 lb. Capacity) Hook Lift

  • Recommended CT: 190″
  • GVW Range: 50,000 lb. or Greater
  • Required Clear Frame (useable) Rail: 245″
  • Chassis Frame Height: Up to 45″
  • Body Lengths: 19′ to 24′
  • Hook Height: Fixed 62″or Adjustable 54″ to 62″
  • Flow: 26 GPM @ 1,500 RPM
  • PSI: 3,500
  • Extras: SL-520 Bid Specs & SL-520 Manual
  • See “400 Series Hoist Links” to the right, for more details.

SL-518 (54,000 lb. Capacity) Hook Lift

  • Recommended CT: 174″
  • GVW Range: 50,000 lb. or Greater
  • Required Clear Frame (useable) Rail: 225″
  • Chassis Frame Height: Up to 45″
  • Body Lengths: 17′ to 22′
  • Hook Height: Fixed 62″or Adjustable 54″ to 62″
  • Flow: 26 GPM @ 1,500 RPM
  • PSI: 3,500
  • Extras: SL-518 Bid Specs & SL-518 Manual
  • See “400 Series Hoist Links” to the right, for more details.
 sl650

SL-650 (65,000 lb. Capacity) Hook Lift

  • Recommended CT: 190″
  • GVW Range: 55,000 lb. or Greater
  • Required Clear Frame (useable) Rail: 249″
  • Chassis Frame Height: Up to 45″
  • Body Lengths: 20′ to 24′
  • Hook Height: Fixed 62″
  • Flow: 32 GPM @ 1,500 RPM
  • PSI: 3,500
  • Extras: SL-650 Bid Specs & SL-650 Manual
  • See “400 Series Hoist Links” to the right, for more details.
